In Virtual Worlds Professional, boundary settings allow you to control the appearance and properties of both plan and elevation boundaries in your 2D diagrams. These settings can be accessed by navigating to the Tools menu, selecting Options, then going to 2D Diagrams, and choosing Boundary Settings.
Plan Boundary Settings
Plan Boundary Settings control the appearance of boundaries in your 2D plans, including the visibility of dimension boundaries.
-
Edit Boundary Properties: Allows you to change the display style, colour, and thickness of the plan boundary.
-
Reset: Reverts any custom boundary changes back to default settings.
- Dimension Boundaries: Toggle this to show or hide dimensioning along the plan boundaries.
Elevation Boundary Settings
The Elevation Boundary Settings control how boundaries are represented on elevation diagrams. These settings allow adjustments for the left, right, top, and bottom boundaries of the elevation.
-
Edit Boundary Properties: Customize the display style, colour, and thickness of elevation boundaries.
-
Reset: Reset any modified boundary properties to default.
-
Dimension Boundary: Toggle this setting to show or hide dimensions at the elevation boundary.
