The General Unit Reference Settings in Virtual Worlds Professional provide control over how references are displayed and positioned for units within your 2D diagrams. You can find these by navigating to Tools and then Options. From here, expand the menus for 2D Diagrams and Unit Settings and select References.
Display References
- Display References: Toggle to enable various annotations, such as schedule numbers, product codes, descriptions, manufacturer details, and annotation titles.
Position
- Position: Select where the unit references should be displayed on a plan (front, back, left, right) and on elevation diagrams (top, bottom, left, right). Additionally, set an offset value using Offset Override.
Rotation
- Rotation: Manually rotate the reference display and specify the degree of rotation required.
Link
-
Show Link From Text to Unit: Toggle to display a visual link between text and the associated unit within the diagram.
